Product description
| Parameter | Description |
|---|---|
| Frequency Range | 902-928 MHz |
| Transmission Method | Frequency Hopping |
| Error Detection | 326/CRC ARQ |
| Transmission Distance | 40 miles (60 kilometers) |
| Transmission Power | 100mW-1W (20-30dBm) |
| Serial Interface | 3.3V CMOS TTL (Optional RS23) |
| Sensitivity | 110dBm @ 115.2kbps |
| -108dBm @ 172.8kbps | |
| -107dBm @ 230.4kbps | |
| Link Speed | 115kbps, 172kbps |
| 230kbps, 276kbps | |
| Routing Modes | Mesh, Auto Routing |
| Store and Forward | |
| Self Healing | |
| Packet Routing | |
| Operating Mode | Encryption: 128-bit AES encryption |
| Power Consumption | Sleep: 1mA |
| Idle: 20mA | |
| RX: 45mA to 98mA | |
| TX: 1000mA to 1400mA | |
| Antenna Interface | UFL |
| Signal Port | 80 SMA |
| Operating Temperature | -40°C to 85°C |
| Operating Humidity | 0-95%, non-condensing |
| Dimensions | 65.2mm x 43.7mm x 13.3mm |
| Certification | FCC/IC |
