High-Bandwidth Gigabit Wireless Microwave Equipment

Product Features

• Wireless Technology: Supports WiFi 7 standard (IEEE 802.11be), with 4096-QAM modulation and 320MHz channel bandwidth. The combination of OFDMA and 16x16 MU-MIMO technology enables concurrent multi-user transmission and efficient spectrum utilization.
• Antenna Design: Equipped with a 20dBi high-gain directional antenna, supporting dual polarization (vertical/horizontal), providing optimized signal coverage and interference resistance. Point-to-point transmission distance can reach up to 15 km (depending on the environment).
• Throughput: Actual tested maximum throughput of 2.3Gbps, with a theoretical peak rate of 23Gbps (single frequency band, under ideal conditions).
• Operating Frequency: 5GHz unlicensed band (5150-6425 MHz), supports Dynamic Frequency Selection (DFS) to avoid interference.
• Hardware Design: The main body is made from die-cast aluminum, meeting the IP67 protection grade, ensuring excellent heat dissipation, wind resistance (can withstand a typhoon level 17), and corrosion resistance. Suitable for harsh environments such as coastal, high-humidity, and high-salt areas.
• Environmental Adaptability: Operating temperature range from -30°C to 60°C, humidity range from 5% to 95% (non-condensing).
• Power Support: Supports 802.3at PoE+ power supply, with low power consumption of under 16W, making it ideal for remote deployment.

Technical Specifications
